| BE-QT8 specification | BE-QT10 specification | |
| Type： | Passive 2-Way System | |
| Frequency Response： | 65Hz-18KHz(±3dB)/60Hz-20KHz(±10dB) | 57Hz-18KHz(±3dB)/47Hz-20KHz(±10dB) |
| HF： | 1*1"(25mm)/1.34"(34mm) | 1*1"(25mm)/1.73"(44mm) |
| LF： | 1*8"(203mm)/2"(51mm) | 1*10"(254mm)/2.56"(65mm) |
| Nominal Impedance： | 8ohm | |
| Sensitivity： | 94dB SPL | 95dB SPL |
| Rated Power： | 180W (AES) | 280W (AES) |
| MAX SPL： | 117dB SPL/123dB SPL peak | 119dB SPL/125dB SPL peak |
| Dispersion： | 80°x 70° | 80°x 60° |
| Connector： | 2 Neutrik NL4MP | |
| Input: | 1+/1- | |
| Link: | 1+/- to 1+/- | |
| Size： | 286×435×260mm(W×H×D) | 335×530×230mm(W×H×D) |
| Packaging： | 360×510×330mm(W×H×D) | 415×610×370mm(W×H×D) |
| Net Weight： | 11.5KG/PCS | 16KG/PCS |
| Gross weight: | 13KG/PCS | 17.5KG/PCS |
