(1) Data is powered and transmitted via FTP Cat5e cable. Therefore, this system supports data transmission of fast Internet services and perfect transmission of audio signals over long distances.
(2) In order to ensure perfect, clear, and highly sensitive sound quality, CMU has built-in high-performance dual-core CPU, 32-bit high-speed DSP technology, feedback suppression, noise elimination, automatic gain, and digital equalization.
(3) Built-in video tracking control and voting processor (BE-9200TS has this configuration but BE-9100TS does not), the high-definition switching matrix can automatically track video with the video matrix.
(4) CMU has built-in USB, which can realize recording and monitoring functions.
(5) Audio can be output in balanced or unbalanced mode.
(6) Ethernet, RS422, RS232 and other interfaces can meet the requirements of different equipment.
(7) Six conference modes are available, namely FREE, REQUEST(1-9), LIMIT(1-9), FIFO(1-9), APPLY and VIP
(8) The connection between CMU and computer can realize various conference functions.
(9)Power input: 230VAC 50/60Hz
(10)Maximum output power: 350W
(11) Frequency response: 100Hz-15KHz
(12) Signal-to-noise ratio: >96dB
(13)Total harmonic distortion: 0.1%@1kHz
(14) Dimensions: 485x 88 x 360 mm, 2 U rack 19” mount
